Vertical turbine drainage pump is mainly used for pumping no corrosion, temperature less than 60 °C, suspended solids (not including fiber, the grits) less than Solid particle 2% by weight (20g/liter) content of the sewage or waste water. VTP type vertical drainage pump is in old type vertical water pumps, and on the basis of the increase and the collar, set the tube oil lubrication is water. Can smoke temperature below 60 °C, send to contain a certain solid grain (such as scrap iron and fine sand, coal, etc.) of sewage or waste water.

PUMP ADVANTAGE

1.The inlet shall be vertical downward and the outlet horizontal above or under the base.

2.The impeller of pump is classified into enclosed type and half-opening type, and three adjustments: non-adjustable, semi adjustable and full adjustable. It is unnecessary to fill the water when the impellers are fully immersed in the pumped liquid.

3.On the basis o Pump, this type is additionally fit with muff armor tubing and the impellers are made of abrasive resistant material, widening the applicability of pump.

4.The connection of impeller shaft, transmission shaft, and motor shaft applies the shaft coupling nuts.

5.It applies water lubricating rubber bearing and packing seal.

6.The motor generally applies standard Y series tri-phase asynchronous motor, or HSM type tri-phase asynchronous motor as requested. When assembling Y type motor, the pump is designed with anti- reverse device, effectively avoiding reverse of pump.

Note before order

1.The temperature of medium shall not be higher than 60 .

2.The medium shall be neutral and PH value between 6.5~8.5. If the medium is not consistent to the requirements, specify in the order list.

3. For VTP type pump, the content of suspended substances in the medium shall be less than 3%;  for VTP type pump, the max. Diameter of solid particles in the medium shall be less than 2 mm and the content less than30 g.

4 VTP type pump shall be connected with clean water or soapy water outside to lubricate the rubber bearing. For two stage pump, lubricant pressure shall not be less than operational pressure.
